Using 150 white LED light source, it has unique optical design, 1 color wheel，2 illusion prism s, 1pc animation gobo with clock wise+counterclockwise rotation effect, 1 pcs Rotation Gobo Wheel with 6 rotation gobos . High efficiency cooling system enables the unit to work safely,which make it a product with higher rate of quantity and price in our moving head series for event production.
Product Specification:
Electrical Voltage 110V ~ 240V Light Source
LED 10W*27pcs LED Lifespan
50000 hours
Control Mode
DMX512 High Efficiency Light Guide Rod + Honeycomb Lens Master/Slave ✅ Auto
✅ RDM Protocol
✅ Update ✅ Optical System Channel standard mode 16CH/ extended mode 20 CH Strobe 1~30t/s CCT 9800K Color Wheel 7color+ white+semi-color effect+bi- direction effect
Effect Gobo Wheel
1pc animation wheel with 3 effects
Rotation Gobo Wheel
6 rotation gobo+white +shake+bi-direction
Prism Special illusion 6 facet and 4 facet prism ,clock wise+counterclockwise rotation (6 facet linear prism optional)
Angle 8°
Lux 10000lux@5m
PAN/TILT :
PAN:540°; Tilt: 270°,3 phase motor
Cooling system
2 cooling fans(base and head fan)
Physical Machine N.W 13Kg Machine Size 298*228*472mm
Environment& Safty Level of Protection IP20 Stock
Clean and dry place
Running temp. '-10°C~40°C
