YR-COB5002 COB LIGHT

Features:
– Temperature control fan
– Advaced dimmer system
– Mini weight 1.5kg
– Adjustable lens angle
– 2260lux @2meter

Share:

Equipped with one 100 W COB LED in warm and pure white,with compact size high luminous low noise and competitive price. Optional barndoors available to provide different lens angle, which make the product suitable for many application.

Product Specification:

Electrical Voltage 110V ~ 240V 50-60Hz
Power Consumption 100W
Light source LED 100W
Color 50W WW+50W PW
Control mode DMX512 5CH/3CH
Master/slave
Manual Control
Housing Light Body Material ABS
Optical System Lens Angle 60°(can change by adding the barndoors)
IP Rate IP20
Phisical Size 26*26*11.5cm
Weight 1.5KG
Environment & safty Stock dry place
Min Working Temperature –20°C
Max Working Temperature 40°C
Noise No noise under 58℃, 44.0dBA @0.5meter(above 58℃), 46.1dBA close to fixture
Temperature Control Fan with low noise temperature control fan, the fan will work until the led board reach 58~60℃, and the fan will stop working when the fan reduce to 40℃
Lux@(w/o fresnel lens/w/fresnel lens)Full Color/Each Color2 Meter1 Meter
Full Color (2260 lux without fresnel lens or 2680 lux with fresnel lens ) (7570 lux without fresnel lens or 10500 lux with fresnel lens)
WW (1210 lux without fresnel lens or 1400 lux with fresnel lens) (3900 lux without fresnel lens or 5700 lux with fresnel lens)
PW (1100lux without fresnel lens or 1300 lux with fresnel lens) (3680 lux without fresnel lens or 5000 lux with fresnel lens)
